BlackBox TM66 Asset Tracker
Description
Technical Specifications
Features
Description
Blackbox TM 66 Asset trackers are made to protect your valuables, including trucks, trailers, containers, farm equipment, and other items. With an asset GPS tracker, you can monitor your item from any location at any time. It offers real-time monitoring and can instantly send an alarm in case of any emergency. Since it is a plug-and-play device, so usage is simple with a battery backup of 10-15 days!
Technical Specifications
| GSM Specification | |
|---|---|
| GSM | M66 – Quectel Quad-band 850/900/1800/1900MHz |
| GPRS | Multi-slot Class 12, Speed 86Kbps |
| Protocols | TCP/IP |
| SIM | Neon SIM Card |
| SMS | Text SMS OTA Command Support |
| FOTA | FOTA FTP support |
| GPS Specification | |
| GPS | L76/Optional L79D GPS L1 Band (1575.42MHz ) GLONASS L1 Band ( 1601.71MHz ) SBAS : WAAS, EGNOS MSAS |
| GPS Channels | 33 (Tracking) / 99 (Acquisition) |
| Horizontal Position Accuracy | <2.5 m CEP |
| Velocity Accuracy | <0.1m/s |
| Acceleration Accuracy | 0.1 m/s² |
| Cold Start Warm Start Hot Start | <35s <30s <1s |
| Sensitivity Acquisition Tracking Reacquisition | -148dBm -165dBm -160dBm |
| Micro Controller and IO’s Specification | |
| Micro-controller | Nuvoton NUC131 32 bit ARM Cortex™-M0 Processor With 50MHzPLL Clock , 32KB SRAM , 64KB Code Memory |
| Flash Memory | 64 M-Bit for Data logging up to 50000 data packs |
| Li-ion Battery | 10000mAH |
| LED’s | GREEN – ON during battery charging. , Blinks on Low battery RED- Blinks when sending data. Yellow – GPS Signals Reception. Blue – Blinking when device is active. |
| Housing Specification | |
| Housing Type | ABS Plastic |
| Connector | DC jack |
| dimensions | Length : 100 mm Breath : 80 mm Height : 35 mm |
Features
- Power Backup of 10 – 15 Days
- Asset Tracker Removal Alert (Exteraction)
